Product Details:
Place of Origin: China
Brand Name: OEM
Certification: ISO9001, 3A
Model Number: OEM
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Plywooden case
Delivery Time: 7-15 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10,000pcs per month

Pneumatic Controls 2 Inch Butt Weld Hygienic Butterfly Valve

Description
Material: SS316L Style: Butterfly Hygienic Valve
Connection Type:: Butt Welded Ends Size: 1/2"-12"
Standard: 3A ASME BPE MOQ: 1PC
High Light:

2 Inch Butt Weld Butterfly Valve

,

Butt Weld Hygienic Butterfly Valve

,

2 Inch Butterfly Hygienic Valve

2 Inch Hygienic Butt Weld Butterfly Valve High Corrosion Resistant Easily Welded

Description

Butterfly valves can be actuated either manually or pneumatically. There is a wide range of manual controls to meet the different system requirements. Pneumatic controls can be horizontal and vertical, single-, double-effect, and modulating. They can be fitted with control tops and proximity It is widely applied to many fileds,such as beer,beverage,dairy food,fruit juice,pharmacy,biological etc.





Technical Parameters



Standard 3A,SMS,DIN,ISO,RJT,IDF
Product wetted steel parts AISI304/AISI316L Provided with material inspection report
Other steel parts AISI304
Size 3/4"~6",DN20~DN150,19mm~152.4mm
Seal material EPDM/VMQ/FPM All seals material comply with FDA21CFR117.2600
Working pressure ≤10bar(145psi)
Supply pressure for air actuator 5~8(0~116psi)
Working temperature EPDM:-14~248ºF(-10~120ºC)
VMQ:-58~356ºF(-50~180ºC)
FPM:22~446ºF(-30~230ºC)
Other materials are avaible upon request
Sterilization temperature 302ºF(150ºC,max 20min)
Outside surface treatment Ra16~32uin(o.4~0.8um)
Inside surface treatment Ra32~64uin(o.8~1.6um)
Connetion ends butt-weld,clamped ends,male ends, flange ends
Pneumatic head Normally closed(NC)-Air to open,spring to close
Normally open(NO)-Air to close,spring to open
Air to air(AA)-Air to open,air to close



Sanitary stainless steel 316L tri-clampe hygienic butterfly valves with Ss Gripper Handle







Pneumatic Controls 2 Inch Butt Weld Hygienic Butterfly Valve 1







Options


1.The seat and gasket can be NBR (Nitrile), VMQ (Silicone) or Viton (FPM) all complying with FDA 21CFR177.2600.
2. End connection can be butt-welded, sanitary clamp, threaded, flanged, I-line or others upon request.
3.Handle: 3-position pull handle; multi-position handle in either pure stainless steel or with plastic cover.
4.Actuator: pneumatic stainless steel actuator (vertical type), pneumatic aluminum actuator (horizontal type), electric actuator.
5.Control: position sensor, C-top controller, C-top controller (AS-I)



Design Features
1.Various standards can be provided: DIN, 3A, SMS, ISO / IDF, BS / RJT, and ASME / BPE.
2.Available in sizes from DN25 / 1" to DN300 / 12"
3.Multiposition handles can be used for valves up to DN100 / 4";
4.Pull handles can be used for valves from DN25 / 1" to DN300 / 12"
Manual handle,
5.pneumatic actuator and electric actuator are interchangeable.
6.Seals comply with FDA 21CFR 177. 2600.
7.The valve body can be customized with a wide selection of different connections.

Sanitary stainless steel 316L tri-clampe hygienic butterfly valves with Ss Gripper Handle



We also supply sanitary butterfly valve, sanitary flow diversion valve, sanitary CPM valve, sanitary regulating control valve, sanitary diaphragm valve, sanitary ball valve, sanitary sampling valve, sanitary safety valve, sanitary pressure reducing valve
